IO-Link Master Stack
Current sensors and actuators in industrial automation are often equipped with small, powerful microprocessors that allow these sensors to be provided with useful functionality, such as remote parameterization or diagnostic capabilities. However, this functionality is not visible in standardized planning or control systems when using proprietary communication interfaces.
IO-Link, the bi-directional, digital communication standard (IEC 61131-9), offers the possibility of standardized mapping of sophisticated sensors and actuators into these systems.
Our IO-Link Master Software Stack provides automation system providers or machine builders with a quick and easy means to integrate IO-Link technology into their system environment.
Would you like to test our IO-Link Master Stack?
Master Stack Features
- Complies with the current IO-Link Interface Specification V1.1.5
- Multi-port support. The maximum number of ports is only resource-limited.
- Minimum cycle times:
- 0.4ms @ 230.4 kBaud
- 2.3ms @ 38.4 kBaud
- 18ms @ 4.8 kBaud
- Processor load max. 20MHz/Port (COM3)
- Control and Test API
- IO-Link SMI API support according to v1.1.3 specification (extended Fieldnet mapping support with our TSTL API)
Implementation
The IO-Link Master Stack firmware provides full access to all features and services defined in the IO-Link Interface Specification V1.1.2. This includes support for ISDUs, events, Data Storage, and Interleaved Mode. Please note the following:
- A real-time operating system is required. The RTOS is accessed through an abstraction layer, allowing support for multiple real-time operating systems. FreeRTOS, OpenRTOS, embOS, and Keil RTX are currently supported.
Processors and ASICs Supported by the Master Stack
Examples of Existing MCUs
STMicroelectronics
- STM32F1, STM32F3, STM32F4 & STM32F7
- STM32G0
- STM32H7
- STM32L4
Renesas
- RA4M2
- RL78
- RX231
Other
Asix:
- AX58400
Silicon Labs:
- EFR32MG24
Beispiele für bestehende IO-Link ASICs:
STMicroelectronics
- L6360
Analog Devices
- LTC2874
- MAX14819
- MAX14824
Renesas
- CCE4510
- CCE4511
- ZIOL2401
Texas Instruments
- TIOL112
Compilers and Development Environments Supported by the Master Stack
- KEIL-MDK
- IAR Toolchain
- Eclipse/GNU-GCC Toolchain / NXP LPCXpresso
Master Stack Licensing Information and Scope of Delivery
- Development license, including complete source code
- Production license
- Porting to target hardware
- Documentation, installation manual, and porting description
- API interface documentation
- Example application
- Compiler & Linker example setup
- IO-Link configuration software with IODD Interpreter for commissioning tests
Please contact our sales team for further details on licensing, the scope of delivery, and the practical implementation of your project.
Additional Offerings for the Master Stack
- Development platforms
- Software/Hardware Development Support
- Conformity tests (with TEConcept Master Tester)
Control Tool Software
Control Tool (CT) software for operating the stack from a PC simplifies integration into the customer application and provides straightforward options for testing and comparing the stack’s functionality.
