IO-Link EMC Test Master - EMC conformity tests for IO-Link Devices
The IO-Link specification defines procedures for testing the EMC robustness of IO-Link Devices, which can be verified by TEConcept’s IO-Link EMC Test Master. Among other things, the sensitivity of IO-Link communication of IO-Link Devices under EMC conditions is examined. This requires a robust Master that is far less sensitive to EMC noise than the device under test. This is achieved by separating the IO-Link Master into two parts: Part 1 contains the sensitive digital logic (µC box), Part 2 contains the IO-Link transceiver (PHY box). Both parts are separated by an optical connection with a length of up to 10 m.
Do you want reliable testing of your IO-Link Device's EMC immunity?
IO-Link EMC Tester Specifications
- Complies with IO-Link Interface Specification V1.1.2 and the current IO-Link test specification.
- Error and signal output
- 4 electrical IO-Link Port configurations COM1 / 2 Port (good signal) COM1 / 2 Port (bad signal) COM3 Port (good signal) COM3 Port (bad signal)
- RS232 and USB interfaces
- Terminal-based control command set
- Additional EMC test and control software with graphical user interface
- Test report generation in PDF format
- Can be configured for operation as a standard “USB IO-Link Master“
- Firmware update supported
Benefits offered by the IO-Link EMC Test Master
- Sensitive parts are located outside the EMC chamber
- EMC robustness significantly better than required
Further test systems for your IO-Link Device project
In addition to the EMC test, the protocol test and the physical layer test are also required for a complete IO-Link certification (Test & Quality IO-Link Community). To achieve this goal with minimal effort, TEConcept offers further diagnostics & test tools that can be used directly by members of the IO-Link Community for issuing the required certifications. For non-members, TEConcept, as an accredited IO-Link Competence and Test Center, carries out the certification tests.
IO-Link Device Tester
Automatically checks the protocol conformity of IO-Link Devices according to the IO-Link test specification. With IODD-based configuration and detailed test reports — approved by the IO-Link Community for standard-compliant conformity tests.
IO-Link Physical Layer Tester
Checks the electrical interface of IO-Link Devices: signal levels, bit timing, and current consumption according to the IO-Link specification. Automatically generates a report — a prerequisite for IO-Link certification.
IO-Link Diagnosis Tool
Enables parameterization, process data evaluation, and device diagnostics of IO-Link Devices directly on the PC — ideal for commissioning, Field Operation, and technical support.
